Features
- Electromagnetically Matched Magnets and Stator
- High-strength 4mm Titanium Alloy Shaft
- Japanese NSK 11 × 5 × 5 bearings
- 7075 Aluminum Bell and Base
- N52H Arc Curved Magnets
- Hex Bolt Shaft Set Screw
- Protected Motor Wires
- Dynamically Balanced
- Unibell Design
Specifications
1300KV
- Winding: Single-strand copper winding
- Bearing Dimensions: φ11 × φ5 × 5mm
- Mounting Holes: 19 × 19mm, φ3mm
- Shaft Protruding Length: 15.5mm
- Interphase Resistance: 48.5mΩ
- Lead Length: 265mm / 18AWG
- Dimensions: φ35.06 × 21.3mm
- Rotor Specifications: Unibell
- Max Wattage: 1681.0W
- Magnets: N52H Curved
- Configuration: 12N14P
- Peak Current: 48.33A
- Shaft Diameter: 5mm
- Input Voltage: 24V
- Bearing Type: NSK
- Weight: 49.5g
- KV: 1300KV
1800KV
- Winding: Single-strand copper winding
- Bearing Dimensions: φ11 × φ5 × 5mm
- Mounting Holes: 19 × 19mm, φ3mm
- Shaft Protruding Length: 15.5mm
- Interphase Resistance: 72.29mΩ
- Lead Length: 265mm / 18AWG
- Dimensions: φ35.06 × 21.3mm
- Rotor Specifications: Unibell
- Max Wattage: 1132.9W
- Magnets: N52H Curved
- Configuration: 12N14P
- Peak Current: 72.3A
- Shaft Diameter: 5mm
- Input Voltage: 24V
- Bearing Type: NSK
- Weight: 53.3g
- KV: 1800KV
Includes
- 1xiFlight Xing 2806.5 Race Motor (Choose Your KV)
- 1x Hardware Kit
